A New Method to Evaluate the Dynamic Air Gap Thickness and Garment Sliding of Virtual Clothes During Walking

Pengpeng Hu, Edmond S. L. Ho, Nauman Aslam, Taku Komura and Hubert P. H. Shum
Textile Research Journal (TRJ), 2019

 Impact Factor: 2.3 Citation: 15#

A New Method to Evaluate the Dynamic Air Gap Thickness and Garment Sliding of Virtual Clothes During Walking
# According to Google Scholar 2023"

Abstract

With the development of e-shopping, there is a significant growth in clothing purchases online. However, the virtual clothing fit evaluation is still under-researched. In the literature, the thickness of the air layer between the human body and clothes is a dominant geometric indicator to evaluate the clothing fit. However, such an approach has only been applied to the stationary positions of the manikin/human body. Physical indicators such as the pressure/tension of a virtual garment fitted on the virtual body in a continuous motion are also proposed for clothing fit evaluation. Both geometric and physical evaluations do not consider the interaction of the garment with body e.g. sliding of the garment along the human body. In this study, a new framework is proposed to automatically determine the dynamic air gap thickness. First, the dynamic dressed character sequence is simulated in a 3D clothing software via importing the body parameters, cloth parameters and a walking motion. Second, a cost function is defined to convert the garment in the previous frame to the local coordinate of the next frame. The dynamic air gap thickness between clothes and the human body is determined. Third, a new metric called 3D garment vector field (3DGVF) is proposed to represent the movement flow of the dynamic virtual garment, whose directional changes are calculated by cosine similarity. Experimental results show that our method is more sensitive to the small air gap thickness changes compared with start-of-the-arts, allowing it to more effectively evaluate clothing fit in a virtual environment.

Downloads

YouTube

Citations

BibTeX

@article{hu19newmethod,
 author={Hu, Pengpeng and Ho, Edmond S. L. and Aslam, Nauman and Komura, Taku and Shum, Hubert P. H.},
 journal={Textile Research Journal},
 title={A New Method to Evaluate the Dynamic Air Gap Thickness and Garment Sliding of Virtual Clothes During Walking},
 year={2019},
 volume={89},
 number={19--20},
 pages={4148--4161},
 numpages={14},
 doi={10.1177/0040517519826930},
 publisher={SAGE},
}

RIS

TY  - JOUR
AU  - Hu, Pengpeng
AU  - Ho, Edmond S. L.
AU  - Aslam, Nauman
AU  - Komura, Taku
AU  - Shum, Hubert P. H.
T2  - Textile Research Journal
TI  - A New Method to Evaluate the Dynamic Air Gap Thickness and Garment Sliding of Virtual Clothes During Walking
PY  - 2019
VL  - 89
IS  - 19--20
SP  - 4148
EP  - 4161
DO  - 10.1177/0040517519826930
PB  - SAGE
ER  -

Plain Text

Pengpeng Hu, Edmond S. L. Ho, Nauman Aslam, Taku Komura and Hubert P. H. Shum, "A New Method to Evaluate the Dynamic Air Gap Thickness and Garment Sliding of Virtual Clothes During Walking," Textile Research Journal, vol. 89, no. 19--20, pp. 4148-4161, SAGE, 2019.

Supporting Grants

Erasmus Mundus
Sustainable Green Economies through Learning, Innovation, Networking and Knowledge Exchange (gLink)
Erasmus Mundus Action 2 Programme (Ref: 2014-0861/001-001): €3.03 million, Co-Investigator, Northumbria University Funding Management Leader (PI: Prof. Nauman Aslam)
Received from Erasmus Mundus, 2015-2018
