Fast, Efficient Phasing of Deployable Space Telescopes using Machine Learning

Daniel Martin, Cyril Bourgenot, Andrew Reeves and Hubert P. H. Shum
Optics Express, 2026

Impact Factor: 3.3

Fast, Efficient Phasing of Deployable Space Telescopes using Machine Learning

Abstract

A fast, two-step piston sensing technique has been developed to enable diffraction limited imaging. Achieving such performance requires a Strehl ratio exceeding 0.8, which corresponds to a wavefront RMS error below 32 nm at λ = 450 nm. A machine learning model has been implemented for a four-petal telescope to retrieve piston errors directly from PSF images and enable mirror correction. When tested on synthetic misalignments drawn from a uniform distribution within ±300 nm ( or ±2λ/3), the model improved the mean Strehl ratio from a degraded state to 0.95 after one iteration, and to 0.99 after a second iteration. An SNR greater than 40 was found sufficient to achieve phasing corresponding to a Strehl ratio of at least 0.97.


Downloads


YouTube


Cite This Research

Plain Text

Daniel Martin, Cyril Bourgenot, Andrew Reeves and Hubert P. H. Shum, "Fast, Efficient Phasing of Deployable Space Telescopes using Machine Learning," Optics Express, Optica, 2026.

BibTeX

@article{martin26fast,
 author={Martin, Daniel and Bourgenot, Cyril and Reeves, Andrew and Shum, Hubert P. H.},
 journal={Optics Express},
 title={Fast, Efficient Phasing of Deployable Space Telescopes using Machine Learning},
 year={2026},
 publisher={Optica},
}

RIS

TY  - JOUR
AU  - Martin, Daniel
AU  - Bourgenot, Cyril
AU  - Reeves, Andrew
AU  - Shum, Hubert P. H.
T2  - Optics Express
TI  - Fast, Efficient Phasing of Deployable Space Telescopes using Machine Learning
PY  - 2026
PB  - Optica
ER  -


Supporting Grants
